| Coad | 671707 | Type | Plane Dichroic Mirror | |
| Dimension(mm) | 25.4 x 2.0 | AOI(°) | 17 | |
| Diameter | 25.4mm +0/-0.1mm | Thickness | 2.0mm +0/-0.1mm | |
| HR Wavelength (nm) | 640 - 780 | HT Wavelength (nm) | 1550 - 2500 | |
| Substrate | IRFS Suprasil 300 | Clear Aperture | 22mm | |
| Parallelism | <3 arcsec | Protective Chamfer | 0.1-0.4mm x 45° | |
| Surface Quality S1 | MIL 10/5 S/D | Surface Quality S2 | MIL 10/5 S/D | |
| Surface Flatness | <λ/6@633nm over any 10mm dia within CA | Coating Type | IBS | |
| Reflectivity | >98% | Transmittance | >95% | |
| Coating Parameter S1 | HRp>98%@640-780nm+HTsp>95%@1550-2500nm | Coating Parameter S2 | ARsp<1%@1550-2500nm |
Traders City price 418.00$ The different purchase price may be caused by the store's previous promotion activities. For details, please consult the seller
