| Coad | 671470 | Type | Fast Liquid Crystal Variable Retarder | |
| Enclosure Dimensions (mm) | 25.7 x 9.0 | Wavelength(nm) | 700 - 1100 | |
| Clear Aperture（mm） | 10.00 | Optical Retardance | 0.5λnm - 5.5λ | |
| Optical Component Material | Nematic Liquid Crystal / ITO Glass | Operating Temperature | -20 - 45℃ | |
| Response Time (Rise/Fall) | 700ms / 200ms@1064nm | Delay Uniformity | <λ/100 | |
| Surface Quality | 40-20 | Transmitted Beam Deflection (With Mechanical Housing) | <10arcmin | |
| Transmitted Beam Deflection (Without Mechanical Housing) | <1arcmin | Transmission Wavefront Deviation | <λ/4@632.8nm | |
| Coating Type | AR Coating | Coating Specifications | Ravg<0.5%@700-1100nm，AOI=0°，AR>87%@700-1100nm |
Traders City price 789.00$ The different purchase price may be caused by the store's previous promotion activities. For details, please consult the seller
