| Coad | 671343 | Type | Fixed-Gain Photodetector | |
| Dimension(mm) | 40.0 x 50.0 x 50.0 | Wavelength(nm) | 400 - 1100 | |
| Bandwidth (MHz) | DC-50 | Photosensitive Area Diameter (mm) | 1.2 x 1.2 | |
| Storage Temperature | -25 - 70℃ | Operating Temperature | 10 - 50℃ | |
| NEP | 6.3pW/√Hz | Rise Time | 7.0ns | |
| Maximum Optical Power | 1.27mW@850nm | Minimum Optical Power | 170nW@850nm | |
| Maximum Output Voltage | 0-3.5V（50Ω）0-7V（High-Z） | Sensitivity | - | |
| Power Supply | ±9.0 V DC，100mA | Electrical Output Type | BNC | |
| Peak Spectral Responsivity | 0.55A/W@850nm | Accumulated Noise (RMS) | 800.0μV | |
| Transimpedance Gain | 25kV/A（50Ω）50kV/A（High-Z） | Detector Type | Silicon photodetector |
Traders City price 491.00$ The different purchase price may be caused by the store's previous promotion activities. For details, please consult the seller
