| Code | 670428 | Type | Helium-Neon Lasers | |
| Operating Wavelength | 632.8nm | Housing Dimensions | Ø54.5mm × 302mm | |
| Output Power | >1.0mW | Polarization Extinction Ratio | >1000：1 | |
| Beam Diameter | 0.54mm | Output Mode | TEM₀₀ | |
| Amplitude Stability | ≤ ±0.1% (8 hours) | Frequency Stability | ≤ ±1MHz | |
| Beam Divergence (Full Angle) | 1.50mrad |
High amplitude stability ≤ ±0.2% (1 month)
Fixed polarization, ideal for polarization-related experiments
Excellent beam monochromaticity, coherence, and directionality with long lifetime
LBTEK frequency-stabilized He-Ne lasers are single longitudinal mode, high-stability lasers with a coherence length of over 300 m. Their exceptional stability and high polarization extinction ratio make them widely used in precision metrology, spectroscopic standards, and other high-accuracy applications.
Designed for strong adaptability and reliable operation, these He-Ne lasers are plug-and-play with long service lifetimes. When paired with the HM-V50 V-mount holder, they can be easily integrated into experimental optical setups.
