| Coad | 670418 | Substrate | Liquid Crystal Polymer / N-BK7 / Linear Polarizer Film | |
| Type | Collimation and Homogenization Converter | Clear Aperture | 15.0mm | |
| Dimension(mm) | 25.4 x 3.0 | Transmission Area Width | 0.44mm | |
| Wavelength(nm) | 633 | Housing Specification | SM1-8A | |
| Incident Beam Diameter (mm) | 2.00 | Incident Beam Quality | Single Mode, M² < 1.3 | |
| AOI | ±5° | Incident Beam Decentering | ±0.1mm(±5% of input beam diameter) | |
| Output Beam Diameter (mm) | 2.00 | Output Beam Uniformity | ＞90%（RMS） | |
| Transmission Light Deviation | <3 arcmin | Transmittance | ＞50% | |
| Surface Quality | 60-40 | Coating Type | AR Coating | |
| Coating Specifications | Ravg＜0.5%@400-700nm | |||
Traders City price 1320.00$ The different purchase price may be caused by the store's previous promotion activities. For details, please consult the seller
