| Coad | 670370 | Substrate | Liquid Crystal Polymer / N-BK7 | |
| Type | Laser Mode Converter | Operating Temperature | -20 - 80℃ | |
| Dimension(mm) | 25.4 x 3.2 | Transmittance | >98%@780nm | |
| Wavelength(nm) | 780 | Gap Between Adjacent Areas | <10μm | |
| Clear Aperture（mm） | 21.50 | AOI | ±15° | |
| Mode Conversion | TEM00→TEM11 | Transmission Light Deviation | ＜10 arcmin / ＜1 arcmin（without mechanical housing） | |
| Optical Retardance | λ/2 | RMS | ±5nm | |
| Delay Accuracy | ±λ/100 | Surface Quality | 40-20 | |
| Coating Type | AR Coating | Coating Specifications | Ravg<0.5%@700-1100nm |
Traders City price 798.00$ The different purchase price may be caused by the store's previous promotion activities. For details, please consult the seller
