| Coad | 670277 | Substrate | Liquid Crystal Polymer / N-BK7 | |
| Type | Polymer Vortex Waveplate | Operating Temperature | -20 - 80°C | |
| Dimension(mm) | 25.4 x 3.2 | Incident Beam Size | 0.05 ~ 21.5mm | |
| Clear Aperture（mm） | 21.50 | Center Offset | ＜0.5mm | |
| Wavelength(nm) | 405 | AOI | ±20° | |
| Order | 16 | Housing Specification | SM1-8A | |
| Optical Retardance | λ/2 | RMS | ±5nm | |
| Transmission Light Deviation | ＜10 arcmin / ＜1 arcmin（Unmounted） | Fast Axis Accuracy | - | |
| Transmittance | ＞85% | Surface Quality | 40-20 | |
| Conversion Efficiency | - | Transmission Wavefront Deviation | ＜λ/4@633nm | |
| Coating Type | AR Coating | Coating Specifications | Ravg＜0.5%@400-700nm |
Traders City price 1132.00$ The different purchase price may be caused by the store's previous promotion activities. For details, please consult the seller
