| Coad | 670073 | Substrate | UVFS | |
| Type | High-Performance Bandpass Filter | OD | avg≥5@300-378nm；abs≥5@413-1100nm；avg≥6@413-1100nm | |
| Diameter(mm) | 25.00 | Diameter Tolerance | +0.0/-0.1mm | |
| Clear Aperture | 22.0mm | Parallelism | - | |
| Thickness(mm) | 3.50 | Thickness Tolerance | +0.0/-0.1mm | |
| Surface Quality | 60-40 | Wavelength(nm) | 395 ±1.5 | |
| Surface Flatness | - | FWHM | - | |
| Transmittance | Tavg≥90%@384-405nm | Mechanical Housing | - | |
| Shell Diameter | - | Housing Diameter Tolerance | - | |
| Outer Shell Thickness | - | Operating Temperature | - | |
| Laser Damage Threshold | - | Transmission Wavefront Deviation | λ@633nm | |
| Coating Radial Angle | - | Coating Type | Dielectric Coating | |
| Protective Chamfer | - | AOI | 0° | |
| Coating Specifications | - | |||
Traders City price 518.00$ The different purchase price may be caused by the store's previous promotion activities. For details, please consult the seller
