| Coad | 669054 | Type | Damage-Resistant Thin-Film Polarizer | |
| Substrate | UVFS Corning 7980 0F | Clear Aperture | 20mm | |
| Dimension(mm) | 25.4 x 6.35 | Parallelism | 10 arcsec | |
| Diameter | 25.4mm +0/-0.1 mm | Thickness | 6.35mm +0/-0.1 mm | |
| Wavelength(nm) | 343 | Surface Quality S1 | 20-10 S-D as per MIL-PRF-13830B | |
| Extinction Ratio | 1000:1 | Surface Quality S2 | 20-10 S-D as per MIL-PRF-13830B | |
| AOI(°) | 45 | Surface Flatness | <λ/10@633nm over 15mm aperture | |
| Coating Type | IBS Polarization / Anti-Reflection (AR) Coating | Coating Parameter S1 | HRs>99.9%+HTp>97%@343nm | |
| Transmission Wavefront Deviation | - | Coating Parameter S2 | ARp<0,15%>@343nm | |
| Laser Damage Threshold | - | |||
Traders City price 346.00$ The different purchase price may be caused by the store's previous promotion activities. For details, please consult the seller
