| Coad | 665907 | Type | Motorized Goniometer Stage | |
| Table Size(mm) | 38.1 x 38.1 | Travel(°) | ±5 | |
| Travel（mm） | - | Axes | - | |
| Material | Aluminum Alloy 6061-T6 | Rotation Center Height | 44.4 ± 0.2mm | |
| Resolution | - | Displacement Stage Height | - | |
| Center Threaded Hole Specifications | - | Platform Mounting Holes | M4/M3 | |
| Thread Hole Spacing | - | Bottom Positioning Hole Type | - | |
| Maximum Speed | - | Backlash | - | |
| Guide Mechanism | - | Drive Mechanism | - | |
| Horizontal Load | 1Kgf | Vertical Load | - | |
| Motion Parallelism | - | Motion Straightness | - | |
| Motion Concentricity | - | Weight | - | |
| Multi-Axis Assembly Method | - | Micrometer Head Minimum Scale | - | |
| Motor Type | - | Surface Treatment | Black Anodizing | |
| Repeatability | - | Unidirectional Positioning Accuracy | - | |
| Accessories Included | M6x8mm cap screws x2 ; 1.5mm and 5mm hex keys (1 each) | Driver Position | Direct Drive at the End | |
| XY Orthogonality | - | Verticality of Z-Axis Motion | - | |
| Rotation Angle | - | End Runout | - | |
| Supplement | - | |||
Traders City price 276.00$ The different purchase price may be caused by the store's previous promotion activities. For details, please consult the seller
