| Code | 664163 | Type | Multimode Optical Fiber | |
| Wavelength Range | 300–2400nm | Numerical Aperture (NA) | 0.22 | |
| Operating Temperature | -190 to +350°C | Fiber Length | 1m | |
| Core Diameter |
600×600μm |
Cladding Diameter | 990μm | |
| Coating Diameter |
1400μm |
Core Material |
Quartz Glass |
|
| Cladding Material |
Fluorine-doped Silica |
OH Content |
low (＜ 1ppm) |
|
| Minimum Bend Radius |
≥49.5mm (short-term mechanical stress) ≥90mm (high laser power use) |
Attenuation @808nm |
8dB/km |
Traders City price 719.00$ The different purchase price may be caused by the store's previous promotion activities. For details, please consult the seller
Square core fiber
Fiber length: 1 meter
Available in ultraviolet/infrared wavelengths
LBTEK offers square core fibers in five sizes: 100×100 μm, 200×200 μm, 400×400 μm, 600×600 μm, and 150×450 μm. Non-circular (square, rectangular) homogenizing fibers have unique modal disturbance characteristics that help in beam homogenization. When Gaussian-distributed laser light is input, a uniform top-hat beam profile can be obtained, with coupling efficiency higher than that of circular fibers. These fibers are the preferred choice for beam shaping applications, such as lighting.
