| Coad | 664070 | Type | Shearing Interferometer | |
| Dimension(mm) | 50.8 x 48.3 x 55.9 | Beam Diameter（mm） | 5.0 - 10.0 | |
| Approximate Optical Path Difference（mm） | 6.60 | Wedge Prism Diameter（mm） | 15.60 | |
| Diameter Tolerance | +0.00/-0.25mm | Wedge Prism Thickness | 2.6mm | |
| Thickness Tolerance | ±0.25mm | Wedge Prism Material | UVFS | |
| Scattering Plate Material | N-BK7 | Scattering Plate Grit | 220 | |
| Wedge Prism Wedge Angle | 40arcsec | Compatible Shear Plate | TSIP100 | |
| Compatible Shear Interferometer | - | |||
Traders City price 456.00$ The different purchase price may be caused by the store's previous promotion activities. For details, please consult the seller
