| Coad | 663925 | Typical Applications | ||
| Type | Low Dispersion 800nm Mirror | Clear Aperture | >90% | |
| Substrate | HPFS 7980 0F | Parallelism | ||
| Diameter(mm) | 25.40 | Surface Quality S1 | 20-10 | |
| Diameter Tolerance | +0/-0.1mm | Surface Quality S2 | ||
| Thickness(mm) | 6.00 | Surface Flatness | λ/8@633nm | |
| Thickness Tolerance | +0/-0.1mm | Laser Damage Threshold | ||
| Wavelength(nm) | 750 - 850 | GDD | Low GDD | |
| AOI(°) | 45 | Coating Type | Dielectric Coating | |
| Coating Specifications | R>99.5%@750-850nm | |||
Traders City price 121.00$ The different purchase price may be caused by the store's previous promotion activities. For details, please consult the seller
