| Coad | 663464 | Type | Plan Achromatic Dry Objective | |
| Wavelength(nm) | 266 - 532 | Work Distance(mm) | 15.00 | |
| Magnification(X) | 20 | Numerical Aperture(NA) | 0.36 | |
| Incident Aperture | 7.2mm | Operating Temperature | 5 - 40 °C | |
| Resolution | - | Mode | - | |
| Immersion Liquid | Air/Dry | Focal Length | 10mm | |
| Numerical Field of View | 1.2mm | Field of View | - | |
| Cover Slip Thickness | N/A | Thread Type | W26 x 0.706mm | |
| Parfocal Distance | 95mm | |||
LBTEK offers Mitutoyo Plan Achromatic Objective Lenses, which feature W26 mm×0.706 mm external threads and are designed with an infinity-corrected Plan Achromatic design for tube lenses with a focal length of 200 mm. The Plan Achromatic Objective corrects axial chromatic aberration, astigmatism, and field curvature for the red, yellow, and blue spectral lines, making it the best type of microscope objective with a flat and clear field of view. LBTEK provides Mitutoyo produced Plan Achromatic Objective Lenses with a working wavelength range of 266 nm to 532 nm and a magnification of 20X.
LBTEK also offers Mitutoyo Plan Achromatic Dry Objective Lenses with a working wavelength range of 266 nm to 532 nm and a magnification of 20X. Each objective features W26 mm×0.706 mm external threads, and using LBTEK's SM1-M26A thread adapter, these lenses can be mounted onto holders with SM1 internal threads. These Plan Achromatic Dry Objective Lenses are suitable for brightfield microscopes. Specific parameters can be found in the product specification table.
